Contrôleur With RS485/232 de logique de PLC de contrôleur de machine programmable de 6 langues
Détails sur le produit:
| Lieu d'origine: | La Chine |
| Nom de marque: | Vector |
| Certification: | CE & FCC |
| Numéro de modèle: | VEC-VE-MU-AN-PLC |
Conditions de paiement et expédition:
| Quantité de commande min: | 1 kit |
|---|---|
| Prix: | To Be Discussed |
| Détails d'emballage: | 144*128*69mm, 176*164*78mm, 316*164*78mm |
| Délai de livraison: | 3-5 jours de travail |
| Conditions de paiement: | L/C, T/T, Western Union |
| Capacité d'approvisionnement: | 500-1000 kits /Month |
|
Détail Infomation |
|||
| Outil de programmation: | Outil de programmation de CODESYS | Langue: | Norme IEC61131-3 |
|---|---|---|---|
| Axe: | Axe multi | Certifictaes: | CE ET FCC |
| Fréquence principale: | 0.4GHz | application: | machine à emballer de masque |
| Surligner: | Contrôleur de machine programmable de FCC,contrôleur de machine programmable de vecteur,contrôleur de logique de PLC de FCC |
||
Description de produit
Programmable Logic Controllers PLC With RS485/232 For Mask Packing Machine
The PLC motion controller uses the CODESYS programming tool, supports 6 programming
languages of IEC61131-3 international standard, and it is easy to use by application engineers.Based
on EtherCAT bus, Unlimited axis, supports local IO expansion, and also supports EtherCAT-based
distributed IO,Without Motion control library.
Products Features
| Products | PLC programmable logic controller |
| Brand | Vector |
| Model No. | VEC-VE-MU-AN-PLC |
| Axis | Multi Axis |
| Progarmming Tool | CODESYS programming tool |
| Programming Language | IEC61131-3 Standard |
| RMain frequency | 0.4GHZ |
| Expansion Units | IO Expansion, Digital, Analog, Encoder, Thermocouple, Hybrid |
| Communication Protocols | EtherCAT Bus,Ethernet communication |
CODESYS Software:
CODESYS software is standard software for the development and application of VE PLC
programmable motion controller products. CODESYS software platform provides VE PLC
controllers with a complete configuration, programming, debugging, monitoring
environment, flexible and free to handle the powerful IEC61131-3 language.
The codesYS software enables the management of engineering and equipment,
providing the following configurations for VE controller products:
1. CPU configuration;
2. I/O module configuration;
3. EtherCAT bus;
4. ModbusRTU/ModbusTCP bus;
5. Standardized programming (IEC61131-3 compliant).
6. Supports all six programming languages: Structured Text (ST), Function Block Chart
7. (FBD), Instruction List (IL), Keystone (LD), Sequential Function Map (SFC), and
8. IEC61131-3 Extended Programming Language Continuous Function Map (CFC)
9. Flexible and comprehensive feature block libraries and support user-defined libraries
10. Offline simulation function,do not need to connect PLC hardware,complete the program simulation debugging
11. Intelligent debugging error check function
12. Compile errors, quickly locate programming errors, and diagnose logs
13. Sample tracking
14. The time series chart of the process variable is established
Products details
The syntax of the IEC 61131-3 specification presents a set of mechanisms for implementing programmable
controllers across different target platforms. Through modular planning and design, the specification divides
control actions into two parts: logical operations and hardware actions. The logical part unifies the syntax
defined in IEC 61131-3 in a common description format and implements it, while the hardware actions are
designed with a proprietary firmware library for each hardware, allowing the control logic to use hardware
resources on each target platform. This design allows different control chips to execute control actions
designed in the IEC 61131-3 syntax, and designers only need to learn the IEC 61131-3 syntax to use
the supported control chips for programmable controller design. The IEC 61131-3 standard defines six
standard programming languages:
(Instruction List,IL)
(Ladder Diagram,LD)
(Function Block Diagram,FBD)
(Structured Text Language,STL)
(Sequential Function Chart,SFC)
(Continuous Function Chart,CFC)
Expansion Units
Packing and Shipping
| Packing details of Motion Controller | |||||
| Products | VA Motion | VA Expansion | VE Motion | VE Expansion(32) | VE Expansion(76) |
| Ctn. Size | 176*165*78 | 127*75*70 | 144*128*69 | 176*164*78 | 316*164*78 |
Delivery Time
| Quantity | 1-5 kits | 50-100 kits | 200-500 kits |
| Delivery time | Within 3 days | 5-10 days | 15-25 days |
1. For small order we always can delivery out within 1 week.
2. Our products can be shippied via Air, Land or Sea.
| Payment Terms: | |||||
| Samples: 100% before delivery by Western Union. | |||||
| Bulk Orders: 30% deposit, 70% before shipping by T/T or Western Union. |
